Home 2009 Dodge Ram 2500 Power Wagon 5.7L V8 - Gas Valve Body, Accumulator, Solenoid and Parking Sprag

Valve Body, Accumulator, Solenoid and Parking Sprag for 2009 Dodge Ram 2500

No.

Part # / Description / Price

Price

Valve Body Assembly ¹

RL354765AB

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION.

Description: NONE

View Details

Valve Body Assembly, Remanufactured ¹

R5166834AF

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION.

Description: NONE

View Details

Transmission Solenoid

68353383AC

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Includes Transmission Range Sensor (TRS). White Connector

MSRP $765.00 CAD

$688.50 CAD

MSRP $765.00 CAD

$688.50 CAD

Shoulder/truss Screw

06508087AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: M5x.8x12.5

View Details

Manual Valve Cam Plate

04799654AC

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $66.95 CAD

$60.26 CAD

MSRP $66.95 CAD

$60.26 CAD

Pan Head Screw

06503232

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: M5 x 0.8 x 12.60

MSRP $2.70 CAD

$2.43 CAD

MSRP $2.70 CAD

$2.43 CAD

Valve Body Detent

52119501AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Use 10/05/02 and after.

View Details

Hex Flange Head Bolt

06101525

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: M6x1.00x30. Valve body to case

MSRP $3.30 CAD

$2.97 CAD

MSRP $3.30 CAD

$2.97 CAD

Screw

06504780AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Pump valve to pump housing.

MSRP $2.95 CAD

$2.66 CAD

MSRP $2.95 CAD

$2.66 CAD

Check Ball

52118261

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. 5.9L I6 HO CUMMINS TD ENGINE. Transmissions: 4-SPD. AUTOMATIC 48RE TRANSMISSION. 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Diameter 0.252 inch

MSRP $4.90 CAD

$4.41 CAD

View Details

MSRP $4.90 CAD

$4.41 CAD

View Details

Transmission Bleed Orifice

04799086

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $16.50 CAD

$14.85 CAD

MSRP $16.50 CAD

$14.85 CAD

Accumulator Seal

04446544

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Same Part Number Is Used For All Twelve Seals

MSRP $14.60 CAD

$13.14 CAD

MSRP $14.60 CAD

$13.14 CAD

Accumulator Spring

04471880

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION.

Description: [LR spring]

View Details

Accumulator Cover

04799598AB

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $10.80 CAD

$9.72 CAD

MSRP $10.80 CAD

$9.72 CAD

Accumulator Spring

52119702AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: [UD, 4C and LR springs]

MSRP $11.05 CAD

$9.95 CAD

MSRP $11.05 CAD

$9.95 CAD

Accumulator Piston

04446620AD

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Same Part Number Is Used For All Six Pistons

MSRP $66.85 CAD

$60.17 CAD

MSRP $66.85 CAD

$60.17 CAD

Clutch Feed Seal

68539966AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $4.50 CAD

$4.05 CAD

MSRP $4.50 CAD

$4.05 CAD

Transmission Valve Body Plate

52119545AB

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION.

View Details

Accumulator Cover Accumulator Kit

05174633AB

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Includes 1 piston, 1 cover and 7 screws

MSRP $90.60 CAD

$81.54 CAD

MSRP $90.60 CAD

$81.54 CAD

¹ This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.

No.

Part # / Description / Price

Price

Transmission Parking Sprag

04799493AD

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $168.00 CAD

$151.20 CAD

MSRP $168.00 CAD

$151.20 CAD

Transmission Snap Ring

04799704

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Park Sprag Gear.

MSRP $11.10 CAD

$9.99 CAD

MSRP $11.10 CAD

$9.99 CAD

Parking Pawl Shaft

04799450

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $6.30 CAD

$5.67 CAD

MSRP $6.30 CAD

$5.67 CAD

Pawl And Rod Kit

05166452AC

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $141.00 CAD

$126.90 CAD

MSRP $141.00 CAD

$126.90 CAD

Torsion Spring

04799451

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $3.05 CAD

$2.75 CAD

MSRP $3.05 CAD

$2.75 CAD

Snap Ring

04799313

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Park Rod to Case.

MSRP $5.80 CAD

$5.22 CAD

MSRP $5.80 CAD

$5.22 CAD

Parking Sprag Pawl Guide

04799774AB

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $42.90 CAD

$38.61 CAD

MSRP $42.90 CAD

$38.61 CAD

456636 - 545RFE; 5-Speed; Automatic Transmission: Pin for Mopar Image

Pin

00456636

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Panel Attaching Pins.

View Details

Screw

06504548

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: M6x1x30

MSRP $12.70 CAD

$11.43 CAD

MSRP $12.70 CAD

$11.43 CAD

Rod Snap Ring

06036682AA

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $4.20 CAD

$3.78 CAD

MSRP $4.20 CAD

$3.78 CAD

Shift Shaft Lever

04799453

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

MSRP $83.05 CAD

$74.75 CAD

MSRP $83.05 CAD

$74.75 CAD

Seal

04799346

Mopar

Notes: Engines: 5.7L HEMI VCT Engine. Transmissions: 5-SPD AUTOMATIC 545RFE TRANSMISSION. 6-Spd Automatic 68RFE Transmission.

Description: Manual Lever Shaft. Latch Adjustment Hole.

View Details

Valve Body, Accumulator, Solenoid and Parking Sprag for 2009 Dodge Ram 2500
